10ft/3.2m I3200 printer
Built for industrial‑scale production, this unit excels in maximum output and uninterrupted high-speed operation.
Print head: Epson i3200 E1-4
Printing width: 3200mm
Print speed: 60sqm/h
Board set: Honson board
Software: Maintop/ Photo print
Printer Features
Four heads up and down capping station
Four heads up and down capping station are independent voltage control and synchronous cleaning. The printer can continue printing normally even if one head encounters fault.
CISS ink supply system
CISS ink supply system ensures uninterrupted high-speed printing, while ink cartridge provides secondary filtration to shield the print head from damage.
Dual aluminum alloy platform’s
Dual aluminum alloy platform’s width significantly larger than dual-head machine, which can improve printing stability.
Honson board set
Honson board set achieves faster printing speed, intelligent head protection, smoother color transition.
Specification
| Model | OLLIN I3200 E1-3200 |
| Print head | I3200 E1 |
| Number of printhead (PC) | 4 |
| Printing width | 3200 |
| Printing speed | 3pass: 60 ㎡/h
4pass: 50㎡/h 6pass: 45㎡/h |
| Compatible ink | Eco solvent ink/Water based ink |
| Cleaning of printhead | Automatic |
| Printing media | SAV/One way vision/Eco light film/PP/Banner flex/Mesh,etc |
| Heating system | Front&Back |
| Software | Maintop/Photo print |
| Working environment | 20-28℃ |
| Voltage | AC220V/110V 50-60HZ |
| Operating System | Window XP/ Window 7/window 10 |
| Packing size | 4600*910*720mm, 610KG |
